| 型号 | 能力螺丝直径mm | 无负荷空转速度rpm | 全长(不包括套筒或者刀头)mm | 重量(不包括套筒或者刀头)kg | 轴心到侧面距离mm | 套筒插入尺寸mm | 软管接头螺纹 | 推荐的软管内径 mm | 空气耗气量m3/min | 噪声值dB(A) | 产品代码 |
| UW-6SLRK | 6 | 8500 | 175 | 0.97 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 91 | 00471 |
| UW-6SARK | 6 | 7500 | 144 | 1.10 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 02371 |
| UW-6SBRK | 6 | 7300 | 144 | 1.10 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 02971 |
| UW-6SHBRK | 8 | 7300 | 154 | 1.36 | 28.0 | 9.5Sq | RC¼ | 9.5 | 0.35 | 91 | 02771 |
| UW-6SLK | 6 | 8500 | 175 | 0.97 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 00431 |
| UW-B6SLK | 6 | 8500 | 166 | 0.97 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 04041 |
| UW-6SK | 6 | 7500 | 170 | 1.22 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 93 | 01031 |
| UW-6SAK | 6 | 7500 | 134 | 1.10 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 93 | 02331 |
| UW-6SHK | 8 | 7500 | 175 | 1.41 | 28.0 | 9.5Sq | RC¼ | 9.5 | 0.35 | 92 | 01831 |
| UW-6SHAK | 8 | 7500 | 153 | 1.36 | 28.0 | 9.5Sq | RC¼ | 9.5 | 0.35 | 92 | 02631 |
| UW-6SLRDK | 6 | 8500 | 182 | 1.00 | 31.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 91 | 00571 |
| UW-6SHBRDK | 8 | 7300 | 170 | 1.40 | 28.0 | 6.35Hex | RC¼ | 9.5 | 0.35 | 91 | 02781 |
| UW-6SLDK | 6 | 8500 | 182 | 1.00 | 31.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 92 | 00531 |
| UW-B6SLDK | 6 | 8500 | 173 | 1.00 | 31.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 92 | 04051 |
| UW-6SDK | 6 | 7500 | 186 | 1.25 | 27.5 | 6.35Hex | RC¼ | 9.5 | 0.30 | 93 | 01131 |
| UW-6SADK | 6 | 7500 | 150 | 1.10 | 27.5 | 6.35Hex | RC¼ | 9.5 | 0.30 | 93 | 02431 |
| UW-6SHDK | 8 | 7500 | 190 | 1.45 | 28.0 | 6.35Hex | RC¼ | 9.5 | 0.35 | 92 | 02531 |
