| 型号 | 能力螺丝直径mm | 无负荷空转速度rpm | 全长(不包括套筒或者刀头)mm | 重量(不包括套筒或者刀头)kg | 轴心到侧面距离mm | 套筒插入尺寸mm | 软管接头螺纹 | 推荐的软管内径mm | 空气耗气量m3/min | 噪声值dB(A) | 产品代码 |
| UW-8SHRK | 8 | 7300 | 172 | 1.55 | 31.0 | 12.7Sq | RC¼ | 9.5 | 0.40 | 93 | 03171 |
| UW-9SRK | 10 | 7000 | 178 | 1.79 | 34.0 | 12.7Sq | RC¼ | 9.5 | 0.45 | 93 | 04171 |
| UW-10SHRK | 10-12 | 6000 | 183 | 2.13 | 35.0 | 12.7Sq | RC¼ | 9.5 | 0.45 | 95 | 05071 |
| UW-13SRK | 12-14 | 6000 | 215 | 2.61 | 37.5 | 12.7Sq | RC¼ | 9.5 | 0.45 | 95 | 06371 |
| UW-8SHK | 8 | 7500 | 172 | 1.55 | 31.0 | 12.7Sq | RC¼ | 9.5 | 0.40 | 95 | 03131 |
| UW-9SK | 10 | 7000 | 178 | 1.84 | 34.0 | 12.7Sq | RC¼ | 9.5 | 0.50 | 95 | 04131 |
| UW-10SHK | 10-12 | 6500 | 183 | 2.13 | 35.0 | 12.7Sq | RC¼ | 9.5 | 0.45 | 97 | 05031 |
| UW-13SK | 12-14 | 6500 | 215 | 2.21 | 37.5 | 12.7Sq | RC¼ | 9.5 | 0.55 | 97 | 06331 |
| UW-9SSK | 10 | 7000 | 290 | 2.10 | 34.0 | 12.7Sq | RC¼ | 9.5 | 0.45 | 95 | 04231 |
| UW-13SSK | 13 | 6300 | 281 | 3.17 | 39.0 | 12.7Sq | RC¼ | 9.5 | 0.55 | 97 | 06531 |
| UW-9CSK | 10 | 7000 | 337 | 2.78 | 34.0 | 12.7Sq | RC¼ | 9.5 | 0.35 | 95 | 04331 |
| UW-13CSK | 13 | 6500 | 374 | 5.17 | 39.0 | 12.7Sq | RC¼ | 9.5 | 0.75 | 100 | 06671 |
